Parameter Category |
Parameter Item |
Specification / Description |
|
Material Parameters |
Material Type |
PS |
|
Material Thickness Range |
0.25mm - 2.3mm (customizable) |
|
|
Color |
Black / White / Custom Pantone |
|
|
Environmental Certification |
SGS Verified / RoHS Compliant |
|
|
Dimension Parameters |
Max Forming Size |
1220 × 740 mm |
|
Max Forming Depth |
≤ 200 mm |
|
|
Dimensional Tolerance |
±0.5mm (standard) |
|
|
Structure Parameters |
Shape |
Customized per customer drawing |
|
Edge Treatment |
Straight edge / Rounded corner / Folded edge / Snap-fit |
|
|
Performance Parameters |
Transparency |
Opaque |
|
Hardness |
High rigidity, good dimensional stability |
|
|
Temperature Resistance |
0°C ~ 50°C (standard PS) |
|
|
Anti-static |
Optional (Surface resistance 10⁶-10⁹Ω for electronics / 10⁹-10¹¹Ω for general anti-static) |
|
|
Mould Parameters |
Mould Type |
Epoxy mould (sampling) / Copper mould (mass production) |
|
Lead Time & MOQ |
Minimum Order Quantity (MOQ) |
2,000 pcs minimum |
|
Sampling Lead Time |
3-5 days (including mould making + sampling) |
|
|
Production Lead Time |
7-15 days (after sample approval) |
|
|
Packaging Parameters |
Packing Method |
PE bag / Carton (as per customer request) |
